Description
|
Product Name |
SpeedyBee Mario Fold 8 DC Long Range Drone |
|
Wheelbase |
DC FLOD:360mm Front:305mm Rear:272mm |
|
Weight |
MARIO Fold 8 DC O3 Kit 695g |
|
Top plate thickness |
2.5mm(T300 3K) |
|
Middle plate thickness |
2.5mm(T300 3K) |
|
Bottom plate thickness |
3mm(T300 3K) |
|
Arm thickness |
7mm(T300 3K) |
|
Camera Screw |
7mm |
|
3D printed par |
Yellow TPU |
|
Stack side plate |
PC |
|
Battery Anti-skid Mat |
Silicone Resin |
|
Motor circlip spacing |
9mm |
|
Propellers |
7-8Inch |
|
Mounting holes for motors |
19mm |
|
FC mounting hole |
30.5x30.5(M3) & 20x20mm (M3) |
|
Drone head |
7075 CNC aluminum alloy |
|
Aluminum standoff |
7075 M3*22mm (5mm&4.6mm) |
|
Internal installation height |
22-31mm |
|
Antenna Mounting |
SMA OR MarioDJI O3 Ant CNC GPS:BZ251 25*25*8mm |
|
Product Name |
SpeedyBee 2807 1050KV Motor |
|
KV (rpm/V) |
1050KV |
|
Shaft Diameter |
Φ5mm |
|
Motor Mounting Hole |
M3X19mm |
|
Rated Voltage(Lipo) |
3-6S |
|
Max. Power (60s) |
1350W |
|
Idle Current |
10V/1.5A |
|
Maximum Curren |
56A |
|
Insulation Meterials Temperature Resistance |
240°C |
|
Weight (incl. Cable) |
47 grams |
|
Size |
Φ34*34mm |
