Wholesale 100pcs Amass XT90I Plug Connectors 4.5mm Gold Bullet Plated Connector Plug Male Female For RC Model Battery

Wholesale 100pcs Amass XT90I Plug Connectors 4.5mm Gold Bullet Plated Connector Plug Male Female For RC Model Battery

Regular price $79.00 USD
Regular price $0.00 USD Sale price $79.00 USD
Sale Sold out
Taxes included.
Color
Size


Amass XT90 2+2 Plug Gold Plated Connector Male Female for RC Aircraft UAV Drone Battery ESC DIY Acc



Specifications:
Brand: AMASS

Product model: XT90 2+2 Connector

Recommended application: Motor / ESC / Battery / Controller

Product color: Yellow

Metal material: Gold Plated

Instantaneous current: 60A 12AWG

Recommended wire gauge: 12AWG / 10AWG / 8AWG

Rated current: 30A 12AWG

Insulation material: PA6

Contact resistance: 0.4m Ω

Working temperature: - 20 ℃ to 120 ℃

Withstand voltage: DC 500V

Recommended usage times: 100 times

Flame retardant grade: UL94-V0

Package included:
100pcs Amass XT90 2+2
