SoloGood.RC
Color: 5 pairs XT90 (2+2)
Price:
$6.49

Description


Amass XT90(2+2) Plug Gold Plated Connector Male Female for RC Aircraft UAV Drone Battery ESC DIY Acc

Specifications:
pls note XT90(2+2） is the same as XT90I, JUST NAME DIFFERENCE
Brand: AMASS

Product model: XT90(2+2) Connector

Recommended application: Motor / ESC / Battery / Controller

Product color: Yellow

Metal material: Gold Plated

Instantaneous current: 60A 12AWG

Recommended wire gauge: 12AWG / 10AWG / 8AWG

Rated current: 30A 12AWG

Insulation material: PA6

Contact resistance: 0.4m Ω

Working temperature: - 20 ℃ to 120 ℃

Withstand voltage: DC 500V

Recommended usage times: 100 times

Flame retardant grade: UL94-V0
